DAGE XD7500NT X-Ray Inspection System | Used DAGE X-Ray Equipment
DAGE XD7500NT is a high-resolution digital X-Ray inspection system designed for SMT, PCBA and electronic assembly inspection.
The system uses sealed transmissive X-Ray tube technology to provide detailed inspection of hidden structures inside electronic assemblies. It is particularly suitable for inspecting BGA, QFN, Flip Chip, CSP and other advanced electronic packages where conventional optical inspection cannot directly identify internal defects.
High-Resolution X-Ray Imaging
Provides detailed visualization of internal structures and hidden defects.
Sealed Transmissive X-Ray Tube
The XD7500NT uses sealed NT950 tube technology, designed to avoid the routine filament replacement associated with traditional open-tube systems.
High Magnification
The XD7500 series supports high-magnification inspection for detailed analysis of electronic components and solder joints. Historical specifications list magnification up to 7,500× for the XD7500NT configuration.
Oblique Angle Inspection
Oblique X-Ray viewing helps operators inspect solder joints and internal structures from different angles, improving defect analysis. Historical XD7500NT specifications list up to 70° oblique viewing.
SMT / PCBA、BGA / CSP、QFN、Flip Chip、Semiconductor Packaging、Automotive Electronics、Power Electronics、Consumer Electronics、Industrial Electronics、Medical Electronics
Voids、Insufficient Solder、Solder Bridging、Open Solder Joints、Component Misalignment、Internal Cracks、Delamination、Hidden Solder Defects
X-Ray inspection is especially useful for defects that cannot be reliably identified through surface optical inspection, providing additional inspection capability for high-density and high-reliability electronic assemblies.
SMT Inspection World provides used DAGE XD7500NT X-Ray inspection equipment for electronics manufacturers worldwide.
Before delivery, used equipment can be professionally inspected and functionally tested according to its actual configuration and condition. We also provide equipment installation, commissioning, maintenance, spare parts and technical support.
Used Equipment Sales、Equipment Rental、Installation & Commissioning、Equipment Maintenance、Spare Parts Supply、Equipment Upgrade、Technical Support
Specializing in brand new & used PARMI 3D Automatic Optical Inspection (AOI) and 3D Solder Paste Inspection (SPI) equipment sales, rental and genuine spare parts supply. With more than ten years of in-depth industry experience, we have served over 50 manufacturing enterprises at home and overseas.
All new and used devices are fully overhauled, precision-calibrated and functionally tested in strict accordance with original factory delivery standards. Every hardware component, software program and optical system is debugged item by item to ensure excellent operating stability and inspection accuracy. All equipment is fully production-ready and can be put into SMT line operation immediately after arrival.
