TRI TR5001E SII ICT Tester | Modular PCBA In-Circuit & FCT Teste
TRI TR5001E SII ICT
Modular MDA / ICT / FCT In-Circuit Tester for High-Density PCBA Mass Production
TRI TR5001E SII is a modular scalable in-circuit tester supporting MDA, ICT and optional FCT functional testing for populated PCB assemblies in SMT mass manufacturing. With up to 3456 test points and 1:1 pin driver/receiver architecture, it delivers high fault coverage for complex, high-density boards, ideal for automotive, industrial and consumer electronics production lines.
The system adopts 6-wire high-precision measurement technology and TRI patented ToggleScan® & Enhanced TestJet, detecting hidden open/short faults even on boards with limited probe access. It supports offline bench configuration or inline SMEMA-compatible integration for automated production lines.
TR5001E SII features 6-wire measurement matrix with auto-guarding function to eliminate fixture resistance interference and ensure stable and accurate component readings. Its exclusive 1:1 driver/receiver per pin design simplifies fixture modification when ECN board changes occur and speeds up test program development & debugging. It runs on Windows 11, with intuitive test editor, waveform display and board view for fast fault pinpointing.
Powered by TRI proprietary test software, TR5001E supports automatic test program generation, real-time fault visualization and smart factory data integration. Typical capabilities include: Boundary Scan, ToggleScan®, TestJet vectorless testing, On-board firmware programming, PXI/LabVIEW external instrument integration, Image enhancement, SPC logging, Yield analysis & custom reporting.
The platform can be upgraded stepwise from basic MDA to full ICT and FCT functional test, protecting your equipment investment.
Supports offline press-type fixture and inline SMEMA compatible conveyor system. The inline version adopts quick-disconnect interface for fast fixture changeover. Multi-core parallel testing option improves throughput for multi-panel boards.
SMT PCBA Mass Production, Automotive Electronics, Industrial Control Boards, Consumer Electronics, Power Electronics, Medical Electronics, High-Density PCB Assembly, Functional Verification
Open Circuits, Short Circuits, Wrong Component Values, Missing Components, Misplaced Components, Cold Solder Joints, Damaged Passive Components, IC Open Pins, Programming Failures
SMT Inspection World supplies pre-owned TRI TR5001E SII In-Circuit Testers for global electronics manufacturers. Prior to shipment, used units will go through professional inspection, functional testing and condition evaluation based on actual hardware configuration.
We also provide:
Equipment Sales, Used Equipment Trading, Equipment Rental, Installation & Commissioning, Maintenance, Spare Parts Supply, Fixture Development, Technical Support
Specializing in brand new & used PARMI 3D Automatic Optical Inspection (AOI) and 3D Solder Paste Inspection (SPI) equipment sales, rental and genuine spare parts supply. With more than ten years of in-depth industry experience, we have served over 50 manufacturing enterprises at home and overseas.
All new and used devices are fully overhauled, precision-calibrated and functionally tested in strict accordance with original factory delivery standards. Every hardware component, software program and optical system is debugged item by item to ensure excellent operating stability and inspection accuracy. All equipment is fully production-ready and can be put into SMT line operation immediately after arrival.
